ABB 6A 1P MCB 3KA

Rated Current (In): 6 A

Poles: 1 Pole (1P)

Tripping Curve: Type C — trips at 5–10 × In, accommodating moderate inrush

Breaking Capacity (Icn/Icu): 3 kA at 230/400 V AC

Rated Voltage: 230 V AC (single‑phase)

Standards: IEC 60898‑1, IEC 60947‑2, SANS 556‑1 compliant

Earth Leakage Protection: Not included

Mounting & Form Factor: DIN‑rail mountable on 35 mm rail, 17.5 mm width

Terminal Connections: Screw terminals for 0.75–25 mm² cable

Ambient Temperature: Operates between −25 °C and +55 °C

Endurance:

• Electrical: 10,000 cycles

• Mechanical: 20,000 operations
