Chint NU6-II 1‑Pole AC Surge Arrester, Type 2, 40 kA, 385 V (Green Light)

Model / Series: NU6‑II G (Type II, Class II surge protective device), 1‑pole DIN‑rail module.

Maximum Continuous Operational Voltage (Uc): 385 VAC, suitable for single-phase low-voltage systems.

Nominal Discharge Current (In): 40 kA (8/20 µs waveform), providing robust protection against high-energy transients.

Standard Compliance: Conforms to IEC/EN 61643‑11, meeting requirements for building and industrial surge protection.

Mounting and Service Features:

• Modular Plug-In Design: Includes a removable protective cartridge and base for quick servicing without circuit interruption.


• Green Indicator Light: Visual status indicator to confirm operational integrity; alerts if replacement is required.
