Chint NH1 Fuse Link – 250 A, gG, 500 Vac / 440 Vdc, NH1 Size

Type: gG (general-purpose for overload and short-circuit protection)
Rated Current: 250A
Fuse Size: NH1
Catalog Number: 521189

• Rated Voltage (AC): 500V

• Rated Voltage (DC): 440V

• Breaking Capacity: 120kA AC

• Utilization Category: gG (full-range protection for cables and equipment)

• Mounting Style: Knife-blade contacts

• Fuse Indicator: Integrated blown-fuse indicator

• Body Material: High-strength ceramic housing

• Conformance: IEC 60269-1 & IEC 60269-2 standards

• Typical Applications: Distribution boards, switchgear, panel protection, and cable protection

• Installation: Requires matching NH1 fuse base or holder

• Weight: Approx. 0.43 kg
