Chint NXR Thermal Overload Relay (7–10 A)

Frame & Setting Range:

• Frame size: NXR‑25

• Adjustable current setting: 7–10 A

Voltage & Motor Compatibility:

• Suitable for systems up to 690 V AC (50/60 Hz), ideal for a wide range of motor protection applications.


Motor Safety Features:

• Provides protection against thermal overload and phase-failure detection, helping to prevent motor damage.

User Functions:

• Includes temperature compensation, action (trip) indication, test/stop button, and manual/automatic reset (manual on this model variant)

• Equipped with 1 NO + 1 NC auxiliary contact for signaling or interlock purposes


Mounting:

• Designed for plug-in installation onto compatible contactors (e.g., Chint NXC series), though it can also be mounted independently with an optional base (MB‑2).


Standards Compliance:

• Conforms to IEC/EN 60947‑4‑1 and IEC/EN 60947‑5‑1, ensuring safe and reliable operation in industrial environments.
