Deye 12 kW 48 V Single‑Phase Hybrid Inverter

DEYE-12.0-230V

🔧 Key Specifications

• The Deye 12kW Single-Phase Solar Hybrid Inverter offers a rated AC output: ~12 000 W (12 kW) single-phase.

• Battery voltage range: 40-60 V DC (48 V nominal system) for lithium-ion or lead-acid batteries.

• Maximum DC input (PV side): ~15 600-19 200 W depending on variant. For example one listing shows max DC input 19,200 W.

• MPPT (maximum power point tracking) input voltage range: e.g., 150-425 V DC for PV strings.

• Ingress protection: IP65 — suitable for outdoor/sheltered mounting.

• Efficiency: maximum efficiency ~97.6%.

• Weight & dimensions: Example listing shows weight ~52 kg, size ~464 × 763 × 282 mm.

✅ Key Features & Benefits

Features

• Hybrid functionality: Combines solar PV input, battery charging/discharging and grid tie features.

• WiFi/remote monitoring support (look for included dongle or integrated connectivity) — enhances system visibility.

• Supports multiple operating modes: On-grid, Off-grid, UPS, battery first, self consumption etc.

• Robust design with IP65 rating allows outdoor or near-outdoor mounting, giving more installation flexibility.

• High PV input and flexible MPPT range allow efficient string design and good solar harvest.

• 48 V battery compatibility means it integrates with common residential battery banks, simplifying system build.

Benefits

• Simplifies solar+battery system architecture by combining major functions into one inverter unit.

• Allows homeowners and small commercial operators to maximise solar energy use and backup capabilities.

• Outdoor compatibility (IP65) saves indoor space and can reduce installation complexity.

• Remote monitoring means system performance tracking, fault detection and easier maintenance.

• Future-proof and scalable: Good for growth if you later add more battery capacity or increase PV.

• High efficiency and flexible input requirements help optimise return on investment.
