Finder 8‑Pin Round Plug‑In Relay – 230 VAC Coil

Coil Voltage: 230 VAC (50/60 Hz)

Contact Configuration: DPDT (Double Pole Double Throw; 2 Form C)

Contact Rating: 10 A at up to 250 VAC, max switching voltage 400 VAC

Load Capability: Approx. 2 500 VA (AC1) or 500 VA (AC15)

Contact Material: Silver‑nickel (AgNi) alloy

Coil Current: Approx. 10.5 mA at full voltage

Coil Power: Approx. 2.2 VA (AC)

Operating Time: ≈ 11 ms; Release ≈ 4 ms

Insulation Rating: 4 kV impulse, dielectric strength 1 000 VAC

Temperature Range: –40 °C to +70 °C

Mechanical Life: > 20 million operations; Electrical life: ~200 000 cycles

Features: Lockable test button with mechanical flag indicator; option for LED or indicator lamp

Mounting: 8-pin (octal) plug-in base; compatible with Finder Series 90 sockets (DIN‑rail or panel mount)
