Hager 32 A 2‑Pole Compact DIN‑Rail Switch Disconnector

Rated Current: 32A

Number of Poles: 2 (Live and Neutral)

Rated Operational Voltage: 230VAC

Rated Insulation Voltage (Ui): 440V

Impulse Withstand Voltage (Uimp): 4kV

Utilization Category: AC-21A / AC-22A

Short-Circuit Capacity:

• Conditional short-circuit current (Icc): 0.48kA

• Short-time withstand current (Icw 1s): 0.48kA

Power Loss: Approximately 3W total (1.5W per pole)

Terminal Capacity:

• Solid conductors: 1.5mm² to 16mm²

• Flexible conductors: 1.5mm² to 10mm²

Mounting Type: DIN rail (1 module wide)

Dimensions:

• Height: 83mm

• Width: 17.5mm

• Depth: 68mm

Ingress Protection: IP20 (when installed in an enclosure)

Operating Temperature Range: -20°C to +50°C

Storage Temperature Range: -40°C to +80°C

Mechanical Endurance: ≥ 200,000 operations

Electrical Endurance: ≥ 25,000 operations at full load

Standards Compliance: IEC 60947-3 / EN 60947-3 / RoHS / REACH compliant
