Hager 63 A 3‑Pole DIN‑Rail Isolator Switch

Rated Current: 63A

Number of Poles: 3 (Three-phase, no neutral)

Rated Operational Voltage: 400VAC

Rated Insulation Voltage (Ui): 440V

Impulse Withstand Voltage (Uimp): 6kV

Utilization Category: AC-21A / AC-22A

Short-Circuit Capacity:

• Conditional short-circuit current (Icc): 0.94kA

• Short-time withstand current (Icw 1s): 0.94kA

• Making capacity (Icm): 1.33kA

Power Loss: Approximately 6.9W total (2.3W per pole)

Terminal Capacity:

• Solid conductors: 2.5mm² to 25mm²

• Flexible conductors: 2.5mm² to 16mm²

Tightening Torque: 2.8Nm

Mounting Type: DIN rail (3 modules wide)

Dimensions:

• Height: 83mm

• Width: 52.5mm

• Depth: 68mm

Ingress Protection: IP20 (when installed in an enclosure)

Operating Temperature Range: -20°C to +70°C

Storage Temperature Range: -40°C to +80°C

Mechanical Endurance: ≥ 60,000 operations

Electrical Endurance: ≥ 5,000 operations at full load

Standards Compliance: IEC 60947-3 / EN 60947-3 / RoHS / REACH compliant
