ATESS Bypass Cabinet – 250kW (Required with PCS250)

Brand: ATESS

Model: Bypass Cabinet – 250kW

Power Rating: 250kW

System Compatibility: Specifically designed for ATESS PCS250

Functionality:

• Provides manual and automatic bypass operation

• Maintains continuous load power during PCS isolation

• Supports inverter maintenance and fault recovery procedures

Voltage Rating: 400V AC (Three-Phase)

Frequency: 50 / 60Hz

Switching Components:

• Heavy-duty circuit breakers or contactors

• Electrically and mechanically interlocked bypass switches

• Integrated disconnects for maintenance safety

Protection & Safety:

• Overcurrent and short-circuit protection

• Arc flash and fault isolation protection

• Safety interlock system to prevent parallel connection errors

• Complies with IEC and industrial safety standards

Enclosure:

• IP54 / IP55 industrial-rated steel enclosure

• Powder-coated for corrosion resistance

• Suitable for indoor or sheltered outdoor installation

Cooling System: Natural or forced-air ventilation (model-dependent)

Applications:

• Commercial and industrial energy storage systems

• Solar + battery hybrid and grid-tied installations

• Data centers, factories, and renewable energy facilities

Key Benefits:

• Ensures uninterrupted power delivery during inverter servicing

• Provides safe and reliable power bypass path

• Simplifies operation and improves system maintainability

• Seamless integration with ATESS PCS250 systems

• Built for long-term durability and compliance
